GETTING STARTED
16
Power Supply
Your P-touch has a rechargeable battery that allows you to use it anywhere when
charged, and an AC adapter that allows you to use it while connected to an electrical
outlet when the battery’s charge becomes low.
Rechargeable Battery
The battery can be recharged by placing the P-touch on the battery charger stand.
Installing the rechargeable battery
Press on the back cover opening grip and open the
back cover.
Slide the battery case cover in the direction of the
arrow and open the case.
Connect the battery as shown in the figure. Make
sure that the wires to the connector match the black
and red stickers on the case.
Power Supply
Connect the AC adapter directly to the P-touch to use it immediately after purchase or when the
battery’s charge becomes low.
• Disconnect power to the P-touch when installing or removing the rechargeable battery.
• Use only the battery charger designed exclusively for the rechargeable battery provided with
your P-touch.
• Do not remove or damage the plastic cover on the rechargeable battery, or use a battery with
the plastic cover removed or damaged.
1
2
3
