Brother P-touch 9700PC User Manual

10
■ LED lamp on USB Direct Interface (PT-9800PCN only)
On Flashing fast
Cutter error Confirm that the tape is not
jammed in the printer. If necessary,
turn the printer off and on with the
power button. If the STATUS lamp
continues to flash, contact your
Brother dealer or Brother Customer
Service.
Roller holder error
Print head overheat error
Turn the printer off and on with the
power button.
On
Flashing very
fast
EEPROM error Turn the printer off and on with the
power button. If the STATUS lamp
continues to flash, contact your
Brother dealer or Brother Customer
Service.
Circuit board error
Off On Booting —
Lamp condition
Condition Remedy
Colour Condition
— Off USB device not connected —
Green On USB device connected —
Red
Flashing HUB connected Disconnect the USB device.
Flashing fast
Noncompliant USB device
connected
Disconnect the USB device.
“Buffer full” error with USB Direct
Interface
Data sent from the bar code reader
is saved on the printer.
Do not use the bar code reader to
consecutively scan bar codes and
do not use the bar code reader with
multiple interfaces at the same time.
Flashing very
fast
Overcurrent
Disconnect the USB device and
turn the printer off and on with the
power button.
Lamp condition
Condition Remedy
Power lamp
(green)
STATUS
lamp (red)

Brother P-touch 9700PC Specifications

General

Vertical printing	Yes
Maximum resolution	360 x 720 DPI
Standard interfaces	USB 2.0
Tape type	TZ
Tape cutting	Automatic
Internal memory	2 MB
Built-in barcodes	Codabar (NW-7), EAN13, EAN8, Maxicode, Postnet, QR Code, UPC-A, UPC-E
Dimensions (WxDxH)	116 x 192.7 x 140 mm
Minimum system requirements for Macintosh	- RAM 128 MB - HDD 50 MB - USB (1.1/2.0)
Minimum RAM	512 MB
Compatible operating systems	Windows 2000 Pro/XP/7/Vista, Mac OS 10.3.9 - 10.6
Maximum label width	27.1 mm
Maximum label length	8 m
Product color	Gray

Weight and Dimensions

Depth	192.7 mm
Width	116 mm
Height	140 mm
Weight	1570 g
