Brother P-touch 9700PC User Manual

13
Connecting to a computer
Connect the printer to a computer using the interface cables. The interface cables used to connect
to a USB port, serial (RS-232C) port and LAN (10/100BASE-TX Wired Ethernet) port are different.
Operation Systems
Basic Setup Serial port
(ESC/P and
P-touch
Template only)
USB port LAN port
PT-9700PC
Windows
®
XP/Windows Vista
®
/
Windows
®
7
Yes No Yes
PT-9800PCN
Windows
®
XP/Windows Vista
®
/
Windows
®
7/Windows Server
®
2003/Windows Server
®
2008/
2008 R2
Yes Yes Yes

Brother P-touch 9700PC Specifications

General

Vertical printing	Yes
Maximum resolution	360 x 720 DPI
Standard interfaces	USB 2.0
Tape type	TZ
Tape cutting	Automatic
Internal memory	2 MB
Built-in barcodes	Codabar (NW-7), EAN13, EAN8, Maxicode, Postnet, QR Code, UPC-A, UPC-E
Dimensions (WxDxH)	116 x 192.7 x 140 mm
Minimum system requirements for Macintosh	- RAM 128 MB - HDD 50 MB - USB (1.1/2.0)
Minimum RAM	512 MB
Compatible operating systems	Windows 2000 Pro/XP/7/Vista, Mac OS 10.3.9 - 10.6
Maximum label width	27.1 mm
Maximum label length	8 m
Product color	Gray

Weight and Dimensions

Depth	192.7 mm
Width	116 mm
Height	140 mm
Weight	1570 g
