Brother P-touch 9700PC User Manual

39
I do not understand how to install the
second printer that I have purchased.
• With a USB connection.
When the printer is connected to the computer using
a USB cable, the driver for the second printer is
automatically installed through Plug and Play.
• With a Peer-to-Peer connection (PT-9800PCN only).
- If one PT-9800PCN is already installed:
After the second printer is connected to the LAN, the
installer starts up and the printer driver is installed. Both
printers are listed in the dialog box where the printer can
be selected. Identify the second printer by its IP address,
and then select it. The selected printer driver is registered
with the computer.
- If multiple printers are to be installed at the same time:
When the printers are connected to the LAN, the installer
starts up and the printer drivers are installed. If multiple
printers are selected in the list appearing in the dialog box
where printers are selected, the selected printer drivers
are registered with the computer.
I do not understand how to share
a printer on a network (PT-9800PCN
only).
See the “Network User’s Guide” (PDF).
Problem Solution

Brother P-touch 9700PC Specifications

General

Vertical printing	Yes
Maximum resolution	360 x 720 DPI
Standard interfaces	USB 2.0
Tape type	TZ
Tape cutting	Automatic
Internal memory	2 MB
Built-in barcodes	Codabar (NW-7), EAN13, EAN8, Maxicode, Postnet, QR Code, UPC-A, UPC-E
Dimensions (WxDxH)	116 x 192.7 x 140 mm
Minimum system requirements for Macintosh	- RAM 128 MB - HDD 50 MB - USB (1.1/2.0)
Minimum RAM	512 MB
Compatible operating systems	Windows 2000 Pro/XP/7/Vista, Mac OS 10.3.9 - 10.6
Maximum label width	27.1 mm
Maximum label length	8 m
Product color	Gray

Weight and Dimensions

Depth	192.7 mm
Width	116 mm
Height	140 mm
Weight	1570 g
