2-6 Getting Ready to Sew
1 —
2 —
3 —
4 —
5 —
6 —
7 —
8 —
?
!
9 —
CONTENTS
Index
1
2
3
▼
4. Pull up the supplemental spool pin and set it in the up
position.
5. Place additional spool of thread on the supplemental
spool pin, so that the thread unrolls from the back.
Then insert a spool cap onto the spool pin all the way
in, to secure the thread spool.
1 Spool pin
2 Spool cap
3 Additional spool of thread
6. Hold the thread from the spool with both hands, and
set the thread in the thread guide.
* Do not set the thread in the bobbin winding thread
guide.
7. Set the thread around the thread guide plate, then pass
the thread through the groove according to threading
sequence (numbers) indicated on the machine.
