Brother ULT-2003D - I Changing the Needle Position (Left Needle Position Patterns Only); I Needle Plate Markings

3-18 Sewing Utility Stitches
1 —
2 —
3 —
4 —
5 —
6 —
7 —
8 —
?
!
9 —
CONTENTS
Index
6
5
1
J
1
234cm
in4
1
8
5
12.0 mm
(1/2 inch)
8.5 mm
(11/32
inch)
5.0 mm
(3/16 inch)
J J JJ
➜ ➜
➜
6.5 mm
(1/4 inch)
➜
➜
➜
1
■ Changing the Needle Position (Left Needle Position Patterns Only)
When you select left needle position stitch patterns, you
can use
and in the Stitch Width display to change
the position of the needle. Match the distance from the
right edge of the presser foot to the needle with the stitch
width, then align the edge of the presser foot with the edge
of the fabric during sewing for an attractive finish.
1 Stitch width
For standard 16 mm (5/8 inch) seam allowance, set
on LCD.
1 16 mm (5/8 inch)
■ Needle Plate Markings
