MATRON-Light with 2250-M Field Guide, Page 4
1. Assembling the MATRON - Light with 2250-M (running BZ7140
Logging and Sound Recording application).
1.1 The MATRON-Light/2250-M system consists of the following components:
1. KE-1015 Outer brief case (includes foam insert)
2. KE-1016 Inner small lockable case (includes foam insert)
3. ZH-0666 Hand switch and cable
4. 2250-M Hand-held analyser running Type BZ7140 Logging and sound recording
application (Version 2.0) including SD memory card Type UL-1009.
5. 4231 Sound Level Calibrator
6. AO-0441-D-030 Microphone extension cable for 2250-M (3m)
7. ZG-0426 Mains Power Supply
8. UA-1251 Fold-flat tripod (only the short extension rod is used with MATRON-
Light the longer extension rod and the rotating head supplied with the tripod are
not used in MATRON-Light)
9. UA- 0588 Tripod adaptor, holder for microphone & preamplifier.
10. UA-1236 Protective cover for microphone
Presentation of stored results and sound recordings by Personal Computer:
11. AO-1476 USB Interface cable to link to Computer – supplied with Type 2250-M
(or a memory card reader – this device is highly recommended for transferring
results).
12. Type 7815 Noise Explorer PC software, OR
13. Type 7820 Evaluator PC software.
Listening to recordings directly from 2250-M or computer:
14. EG-0332 Yamaha powered monitor speaker.
15. EG-8930 High quality headphones.
16. EG-8932 4-way headphone amplifier for use with EG-8930 headphones
17. EG-8933 Cable to connect headphone amplifier (Type EG-8932) to sound card of
PC or to headphone output from 2250
Optional Recording medium:
18. UL-1009: 512MB SD memory card for 2250-M.
19. UL-1013: 512MB CF memory card for 2250-M.
1.2
Assembly of the MATRON-Light system
1.2.1 Before opening the outer case, ensure the “
Bruel & Kjaer
” label under the handle is
the correct way up.
1.2.2 Open the (outer) briefcase by pulling the outer edges of the clips on either side of the
carrying handle.
