Bruker Ascend 400'54 User Manual

71
ZTKS0162 / Z31928 / 04
Technical Data MS 400‘54 Ascend
Dimensions Cryostat Value Unit
C
Operational Ceiling Height
2520 mm
D-RT
Diameter RT Bore Tube
54 mm
D1
Diameter RT vessel
745 mm
D2
Diameter Bottom Plate
795 mm
H1
Height Cryostat (bottom plate to top flange)
1005 mm
H2
Height Cryostat (minimum height for transportation)
1391 mm
H3
Height Cryostat (bottom plate to flow system)
1564 mm
S
Height Magnet Stand (floor to bottom plate)
720 mm
M1
Distance magnetic Center to bottom flange
refer to Table A.14,
page 91
M2
Distance magnetic center to top flange
refer to Table A.14,
page 91
Table A.2: Dimension Cryostat - Front View
