INSTALLING THE PROFILER
This section tells you how to install your new DektakXT stylus profiler. Make sure that the tool is
sitting on the system’s final location with ample access to both front and back. The environmental
enclosure should be sitting on a nearby table.
The first picture below shows a standard DektakXT system. The second picture shows the system
inside its environmental enclosure.
Hood-covered
measurement
head that
includes the
tower, camera,
illuminator, and
sensor head
Scan stage
System base
Sensor head and
stylus
Manual sample-
positioning stage
Block sample
fixture (chuck)
Base foot
