Bruker NMR 400 89 Ascend DNP User Manual

84
ZTKS0243 / Z31993 / 03
Technical Data MS 400‘89 Ascend DNP
Technical Data Sweep Coil
Operating modes of the Sweep Coil:
Sweep Coil Driven Mode
In the driven mode the sweep current lead is mounted and the electricity is flowing
through the sweep power supply. The sweep coil can be energized and de-energized.
Sweep Coil Persistent Mode
In the persistent mode the sweep current lead is mounted but the electricity is flowing
exclusively within the sweep coil.
Technical Data Sweep Coil Value Unit
Sweep coil strength 37.8 G/A
Maximum sweep coil current range ± 20 A
Maximum sweep coil field ± 750 G
Helium evaporation rate (sweep coil driven mode 20 A) 1500 ml/h
Table A.11: Specification of the Sweep Coil
