BRUNSWICK INSTALLATION MANUALPAGE 7
ATTACHING BED CLOTH TO
FRAMED SLATE
Before attaching the billiard cloth, clean slate thoroughly.
FIGURE ONE
Step #1: Lay the bed cloth over the top of the slate, nap side
up, with the nap running from the head end to the foot end
of the table.
NOTE: In determining the direction of the nap, run your
hand lightly over the surface of the cloth. If it meets resis-
tance, it is going against the nap.
Step #2: Leave only enough cloth overhang at the head end
and left side to permit tacking into the wood slate frame.
Leave the balance of cloth overhang at the foot end and
right side.
NOTE: Do not spread tacks on the bed cloth. Keep them in a
container that slides over the cloth.
Step #3: Tack or staple the cloth securely to the wood frame
at #1 with two tacks or staples approximately 2” apart.
Step #4: Stretch the cloth across the table and tack or staple
securely at #2 with two tacks or staples 2” apart.
FIGURE TWO
FIGURE TWO
Step #5: Stretch the cloth from #1 to #3 and tack or staple
securely into the wood frame at the left side of the table.
See Figure B.
Step #6: Stretching the cloth across the table from #3 and
pulling from #2, tack or staple the cloth at #4.
Step #7: On the left side, stretch the cloth tightly from #1
toward the side pocket opening and tack or staple securely
at #5.
Step #8: Repeat Step 5, stretching the cloth from #3 and
tacking or stapling at #6.
Step #9: On the right side of the table, grasp the cloth rmly
and stretch across the table from #5 and toward the side
pocket from #2 and tack or staple at #7.
Step #10: Repeat Step 7, stretching from #6 and toward the
side pocket from #4 and tack or staple at #8.
FIGURE THREE
FIGURE ONE
FIGURE THREE
CENTENNIAL
