Bryant LEGACY 580J User Manual

69
ELECTRICAL INFORMATION
Table 59 – 580J*04A 1--Stage Cooling 3 TONS
V --- P h --- H z
VOLTAGE
RANGE
COMP (ea) OFM (ea) IFM
RLA LRA WATTS FLA TYPE EFF at Full Load FLA
MIN MAX
2 0 8 --- 1 --- 6 0 187 253 16.6 79 325 1.5
Std Static 70% 4.9
Med Static 70% 4.9
2 3 0 --- 1 --- 6 0 187 253 16.6 79 325 1.5
Std Static 70% 4.9
Med Static 70% 4.9
2 0 8 --- 3 --- 6 0 187 253 10.4 73 325 1.5
Std Static 70% 4.9
Med Static 70% 4.9
High Static 80% 5.2
2 3 0 --- 3 --- 6 0 187 253 10.4 73 325 1.5
Std Static 70% 4.9
Med Static 70% 4.9
High Static 80% 5.2
4 6 0 --- 3 --- 6 0 414 506 5.8 38 325 0.8
Std Static 70% 2.1
Med Static 70% 2.1
High Static 80% 2.6
5 7 5 --- 3 --- 6 0 518 633 3.8 37 325 0.6
Std Static 71% 1.9
Med Static 71% 1.9
High Static 80% 2.0
Table 60 – 580J*05A 1--Stage Cooling 4 TONS
V --- P h --- H z
VOLTAGE
RANGE
COMP (ea) OFM (ea) IFM
RLA LRA WATTS FLA TYPE EFF at Full Load FLA
MIN MAX
2 0 8 --- 1 --- 6 0 187 253 21.8 117 325 1.5
Std Static 70% 4.9
Med Static 78% 7.0
2 3 0 --- 1 --- 6 0 187 253 21.8 117 325 1.5
Std Static 70% 4.9
Med Static 78% 7.0
2 0 8 --- 3 --- 6 0 187 253 13.7 83 325 1.5
Std Static 70% 4.9
Med Static 70% 4.9
High Static 80% 5.2
2 3 0 --- 3 --- 6 0 187 253 13.7 83 325 1.5
Std Static 70% 4.9
Med Static 70% 4.9
High Static 80% 5.2
4 6 0 --- 3 --- 6 0 414 506 6.2 41 325 0.8
Std Static 70% 2.1
Med Static 70% 2.1
High Static 80% 2.6
5 7 5 --- 3 --- 6 0 518 633 4.8 37 325 0.6
Std Static 71% 1.9
Med Static 71% 2.1
High Static 80% 2.0
Table 61 – 580J*06A 1--Stage Cooling 5 TONS
V --- P h --- H z
VOLTAGE
RANGE
COMP (ea) OFM (ea) IFM
RLA LRA WATTS FLA TYPE EFF at Full Load FLA
MIN MAX
2 0 8 --- 1 --- 6 0 187 253 26.2 134 325 1.5
Std Static 70% 4.9
Med Static 78% 7.0
2 3 0 --- 1 --- 6 0 187 253 26.2 134 325 1.5
Std Static 70% 4.9
Med Static 78% 7.0
2 0 8 --- 3 --- 6 0 187 253 15.6 110 325 1.5
Std Static 70% 4.9
Med Static 80% 5.2
High Static 81% 7.5
2 3 0 --- 3 --- 6 0 187 253 15.6 110 325 1.5
Std Static 70% 4.9
Med Static 80% 5.2
High Static 81% 7.5
4 6 0 --- 3 --- 6 0 414 506 7.7 52 325 0.8
Std Static 70% 2.1
Med Static 80% 2.6
High Static 81% 3.4
5 7 5 --- 3 --- 6 0 518 633 5.8 39 325 0.6
Std Static 71% 1.9
Med Static 81% 2.0
High Static 81% 2.8
