Bryant LEGACY 580J User Manual

13
Table 8 – PHYSICAL DATA (HEATING) 3 -- 6 TONS
580J**04 580J**05 580J**06 580J**07
Gas Connection
#ofGasValves 1 1 1 1
Nat. gas supply line press (in. w.g.) / (PSIG)
4 --- 1 3 / 0 . 1 8 ---
0.47
4 --- 1 3 / 0 . 1 8 ---
0.47
4 --- 1 3 / 0 . 1 8 ---
0.47
4 --- 1 3 / 0 . 1 8 ---
0.47
LP supply line press (in. w.g.) / (PSIG)
1 1 --- 1 3 / 0 . 4 0 ---
0.47
1 1 --- 1 3 / 0 . 4 0 ---
0.47
1 1 --- 1 3 / 0 . 4 0 ---
0.47
1 1 --- 1 3 / 0 . 4 0 ---
0.47
Heat Anticipator setting (Amps)
1st stage 0.14 0.14 0.14 0.14
2nd stage 0.14 0.14 0.14 0.14
Natural Gas Heat
LOW
#ofstages/#ofburners(total) 1/2 1/2 1/2 1/2
Connection Size 1/2” NPT 1/2” NPT 1/2” NPT 1/2” NPT
Rollout switch opens / closes 195 / 115 195 / 115 195 / 115 195 / 115
Temp erat u r e R ise 25 --- 55 25 --- 55 20 --- 55 15 --- 55
MED
#ofstages/#ofburners(total) 1or2/3 1/3 1/3 1/3
Connection Size 1/2” NPT 1/2” NPT 1/2” NPT 1/2” NPT
Rollout switch opens / closes 195 / 115 195 / 115 195 / 115 195 / 115
Temp erat u r e R ise 55 --- 85 35 --- 65 30 --- 65 25 --- 65
HIGH
#ofstages/#ofburners(total) --- 1or2/3 1or2/3 2/3
Connection Size --- 1/2” NPT 1/2” NPT 1/2” NPT
Rollout switch opens / closes --- 195 / 115 195 / 115 195 / 115
Temp erat u r e R ise --- 50 --- 80 40 --- 80 35 --- 80
Liquid Propane Heat
LOW
#ofstages/#ofburners(total) 1/2 1/2 1/2 1/2
Connection Size 1/2” NPT 1/2” NPT 1/2” NPT 1/2” NPT
Rollout switch opens / closes 195 / 115 195 / 115 195 / 115 195 / 115
Temp erat u r e R ise 25 --- 55 25 --- 55 20 --- 55 15 --- 55
MED
#ofstages/#ofburners(total) 1or2/3 1/3 1/3 1/3
Connection Size 1/2” NPT 1/2” NPT 1/2” NPT 1/2” NPT
Rollout switch opens / closes 195 / 115 195 / 115 195 / 115 195 / 115
Temp erat u r e R ise 55 --- 85 35 --- 65 30 --- 65 25 --- 65
HIGH
#ofstages/#ofburners(total) --- 1or2/3 1or2/3 2/3
Connection Size --- 1/2” NPT 1/2” NPT 1/2” NPT
Rollout switch opens / closes --- 195 / 115 195 / 115 195 / 115
Temp erat u r e R ise --- 50 --- 80 40 --- 80 35 --- 80
Low NOx Gas Heat
LOW
#ofstages/#ofburners(total) 1/2 1/2 1/2 ---
Connection Size 1/2” NPT 1/2” NPT 1/2” NPT ---
Rollout switch opens / closes 195 / 115 195 / 115 195 / 115 ---
Temp erat u r e R ise 20 --- 50 20 --- 50 15 --- 50 ---
MED
#ofstages/#ofburners(total) 1/3 1/3 1/3 ---
Connection Size 1/2” NPT 1/2” NPT 1/2” NPT ---
Rollout switch opens / closes 195 / 115 195 / 115 195 / 115 ---
Temp erat u r e R ise 30 --- 60 30 --- 60 25 --- 60 ---
---
HIGH
#ofstages/#ofburners(total) --- 1/3 1/3 ---
Connection Size --- 1/2” NPT 1/2” NPT ---
Rollout switch opens / closes --- 195 / 115 195 / 115 ---
Temp erat u r e R ise --- 40 --- 70 35 --- 70 ---
