Table 4 – HEATING RATING TABLE -- LOW NO
x
1
UNIT
GAS HEAT
LOW NOx HEAT EXCHANGER
TEMP RISE
(DEG F)
THERMAL
EFFICIENCY
(%)
AFUE
(%)
INPUT / OUTPUT
STAGE 1 (MBH)
INPUT / OUTPUT
STAGE 2 (MBH)
Single Phase
04
LOW --- 60 / 50 20 --- 50 81% 80%
MED --- 90 / 74 30 --- 60 81% 81%
HIGH --- --- --- --- ---
05
LOW --- 60 / 50 20 --- 50 81% 80%
MED --- 90 / 74 30 --- 60 81% 81%
HIGH --- 120 / 101 40 --- 70 81% 80%
06
LOW --- 60 / 50 15 --- 50 81% 80%
MED --- 90 / 74 25 --- 60 80% 81%
HIGH --- 120 / 101 35 --- 70 80% 81%
Three Phase
04
LOW --- 60 / 50 20 --- 50 81% N/A
MED --- 90 / 74 30 --- 60 81% N/A
HIGH --- --- --- --- ---
05
LOW --- 60 / 50 20 --- 50 81% N/A
MED --- 90 / 74 30 --- 60 81% N/A
HIGH --- 120 / 101 40 --- 70 81% N/A
06
LOW --- 60 / 50 15 --- 50 81% N/A
MED --- 90 / 74 25 --- 60 80% N/A
HIGH --- 120 / 101 35 --- 70 80% N/A
NOTE:
1. Units meet Cali fornia’s South Coast Air Quality Management District (SCAQMD) Low---NO
x
emissions requirement of 40
nanograms per joule or less.
Table 5 – SOUND PERFORMANCE TABLE
UNIT
COOLING
STAGES
OUTDOOR SOUND (dB)
A --- W E I G H T E D 63 125 250 500 1000 2000 4000 8000
04A 1 80 90.6 80.9 80.2 76 74.6 71.3 68.5 63.9
05A 1 81 90.9 84.6 79.5 77.9 76.5 71.1 66.9 62.5
06A 1 78 84.0 82.2 76.3 74.8 72.5 68.8 65.6 61.8
07A 1 78 88.8 81.8 76.9 74.4 73.3 69.8 66.3 62.7
08A 1 82 90.1 82.6 81.0 79.4 77.0 73.0 70.4 66.7
08D 2 82 85.8 84.3 80.5 78.7 76.4 72.7 68.3 65.1
09A 1 83 91.2 86.4 81.9 81.0 78.3 73.9 71.4 67.3
09D 2 82 88.6 85.0 81.6 79.5 77.4 74.1 71.0 66.3
12A 1 82 88.6 85.0 81.6 79.5 77.4 74.1 71.0 66.3
12D 2 82 89.0 83.1 80.5 78.5 75.5 71.6 69.6 69.3
14D 2 87 87.0 85.2 84.6 84.9 82.2 78.4 75.3 72.9
16D 2 87 87.0 85.2 84.6 84.9 82.2 78.4 75.3 72.9
LEGEND
dB --- Decibel
NOTES:
1. Outdoor sound data is measure in accordance with
AHRI standard 270--- 2008.
2. Measurements are expressed in terms of sound power.
Do not compare these values to sound pressure values
because sound pressure depends on specif ic environ-
mental factors which nor mally do not match individual
applications. Sound power values are independent of
the environment and therefore more accurate.
3. A ---weighted sound ratings filter out very high and very
low frequencies, to better approximate the response of
“average” human ear. A---weighted measurements for
Bryant units are taken in accordance with AHRI stand-
ard 270--- 2008.
