ELECTRICAL INFORMATION (cont.)
Table 62 – 580J*07A 1--Stage Cooling 6 TONS
V --- P h --- H z
VOLTAGE
RANGE
COMP (ea) OFM (ea) IFM
RLA LRA WATTS FLA TYPE EFF at Full Load FLA
MIN MAX
2 0 8 --- 3 --- 6 0 187 253 19.0 123 325 1.5
Std Static 80% 5.2
Med Static 81% 7.5
High Static 81% 7.5
2 3 0 --- 3 --- 6 0 187 253 19.0 123 325 1.5
Std Static 80% 5.2
Med Static 81% 7.5
High Static 81% 7.5
4 6 0 --- 3 --- 6 0 414 506 9.7 62 325 0.8
Std Static 80% 2.6
Med Static 81% 3.4
High Static 81% 4.4
5 7 5 --- 3 --- 6 0 518 633 7.4 50 325 0.6
Std Static 80% 2.0
Med Static 81% 2.8
High Static 81% 2.8
Table 63 – 580J*08A 1--Stage Cooling 7.5 TONS
V --- P h --- H z
VOLTAGE
RANGE
COMP (ea) OFM (ea) IFM
RLA LRA WATTS FLA TYPE EFF at Full Load FLA
MIN MAX
2 0 8 --- 3 --- 6 0 187 253 25.0 164 325 1.5
Std Static 80% 5.2
Med Static 81% 7.5
High Static 81% 15.0
2 3 0 --- 3 --- 6 0 187 253 25.0 164 325 1.5
Std Static 80% 5.2
Med Static 81% 7.5
High Static 81% 15.0
4 6 0 --- 3 --- 6 0 414 506 12.2 100 325 0.8
Std Static 80% 2.6
Med Static 81% 3.4
High Static 81% 7.4
5 7 5 --- 3 --- 6 0 518 633 9.0 78 325 0.6
Std Static 80% 2.4
Med Static 81% 2.8
High Static 81% 5.6
Table 64 – 580J*08D 2--Stage Cooling 7.5 TONS
V --- P h --- H z
VOLTAGE
RANGE
COMP (Cir 1) COMP (Cir 2) OFM (ea) IFM
RLA LRA RLA LRA WATTS FLA TYPE
EFF at
Full Load
FLA
MIN MAX
2 0 8 --- 3 --- 6 0 187 253 13.6 83 13.6 83 325 1.5
STD 80% 5.2
MED 81% 7.5
HIGH 81% 15.0
2 3 0 --- 3 --- 6 0 187 253 13.6 83 13.6 83 325 1.5
STD 80% 5.2
MED 81% 7.5
HIGH 81% 15.0
4 6 0 --- 3 --- 6 0 414 506 6.1 41 6.1 41 325 0.8
STD 80% 2.6
MED 81% 3.4
HIGH 81% 7.4
5 7 5 --- 3 --- 6 0 518 633 4.2 33 4.2 33 325 0.6
STD 80% 2.4
MED 81% 2.8
HIGH 81% 5.6
