ELECTRICAL INFORMATION (cont.)
Table 68 – 580J*12D 2--Stage Cooling 10 TONS
V --- P h --- H z
VOLTAGE
RANGE
COMP (Cir 1) COMP (Cir 2) OFM (ea) IFM
RLA LRA RLA LRA WATTS FLA TYPE
EFF at
Full Load
FLA
MIN MAX
2 0 8 --- 3 --- 6 0 187 253 15.6 110 15.9 110 325 1.5
STD 80% 5.2
MED 81% 10.0
HIGH 81% 15.0
2 3 0 --- 3 --- 6 0 187 253 15.6 110 15.9 110 325 1.5
STD 80% 5.2
MED 81% 10.0
HIGH 81% 15.0
4 6 0 --- 3 --- 6 0 414 506 7.7 52 7.7 52 325 0.8
STD 80% 2.6
MED 81% 4.4
HIGH 81% 7.4
5 7 5 --- 3 --- 6 0 518 633 5.8 39 5.7 39 325 0.6
STD 80% 2.0
MED 81% 2.8
HIGH 81% 5.6
Table 69 – 580J*14D 2--Stage Cooling 12.5 TONS
V --- P h --- H z
VOLTAGE
RANGE
COMP (Cir 1) COMP (Cir 2) OFM (ea) IFM
RLA LRA RLA LRA WATTS FLA TYPE
EFF at
Full Load
FLA
MIN MAX
2 0 8 --- 3 --- 6 0 187 253 19.0 123 22.4 149 1288 6.2
STD 81% 7.5
MED 81% 10.0
HIGH 81% 15.0
2 3 0 --- 3 --- 6 0 187 253 19.0 123 22.4 149 1288 6.2
STD 81% 7.5
MED 81% 10.0
HIGH 81% 15.0
4 6 0 --- 3 --- 6 0 414 506 9.7 62 10.6 75 1288 3.1
STD 81% 3.4
MED 81% 4.4
HIGH 81% 7.4
5 7 5 --- 3 --- 6 0 518 633 7.4 50 7.7 54 1288 2.5
STD 81% 2.8
MED 81% 2.8
HIGH 81% 5.6
Table 70 – 580J*16D 2--Stage Cooling 15 TONS
V --- P h --- H z
VOLTAGE
RANGE
COMP (Cir 1) COMP (Cir 2) OFM (ea) IFM
RLA LRA RLA LRA WATTS FLA TYPE
EFF at Full
Load
FLA
MIN MAX
208-3-60 187 253 25.0 164 25.0 164 1288 1.5
STD 81% 7.5
MED 81% 10.0
HIGH 81% 17.0
230-3-60 187 253 25.0 164 25.0 164 1288 1.5
STD 81% 7.5
MED 81% 10.0
HIGH 81% 15.0
460-3-60 414 506 12.2 100 12.8 100 1288 0.8
STD 81% 3.4
MED 81% 4.4
HIGH 81% 7.6
575-3-60 518 633 9.8 78 9.6 78 1288 0.6
STD 81% 2.8
MED 81% 2.8
HIGH 81% 6.1
