Table 56 – 580J*16 3 PHASE 15 TON VERTICAL SUPPLY
CFM
Available External Static Pressure (in. wg)
0.2 0.4 0.6 0.8 1.0
RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
4500 487 0.98 552 1.26 610 1.55 665 1.86 718 2.20
4875 515 1.18 578 1.49 633 1.80 685 2.13 735 2.47
5250 544 1.42 604 1.75 657 2.09 707 2.43 754 2.78
5625 572 1.68 631 2.05 682 2.40 730 2.76 775 3.13
6000 601 1.98 657 2.37 707 2.75 753 3.13 797 3.52
6375 630 2.31 684 2.73 733 3.13 777 3.53 819 3.94
6750 659 2.68 711 3.12 759 3.55 802 3.98 843 4.40
7125 689 3.09 739 3.55 785 4.01 827 4.46 867 4.91
7500 718 3.53 766 4.02 811 4.51 852 4.98 891 5.46
CFM
Available External Static Pressure (in. wg)
1.2 1.4 1.6 1.8 2.0
RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
4500 769 2.56 819 2.95 866 3.36 912 3.79 957 4.24
4875 784 2.84 831 3.23 877 3.65 921 4.09 964 4.54
5250 800 3.16 845 3.56 889 3.98 932 4.43 974 4.89
5625 819 3.52
862 3.93 903 4.36 944 4.81 985 5.28
6000 839 3.92 880 4.34 920 4.77 959 5.23 997 5.70
6375 860 4.36 899 4.79 937 5.23 975 5.70 --- --- --- --- --- --- --- ---
6750 882 4.84 920 5.28 957 5.74 --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- ---
7125 904 5.36 941 5.82 --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- ---
7500 928 5.93 --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- ---
NOTE: For more information, see General Fan Performance Notes.
Boldface indicates field supplied drive is required.
Table 57 – 580J**16 3 PHASE 15 TON HORIZONTAL SUPPLY
CFM
Available External Static Pressure (in. wg)
0.2 0.4 0.6 0.8 1.0
RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
4500 479 0.97 540 1.23 596 1.50 651 1.80 703 2.13
4875 508 1.19 566 1.47 619 1.75 670 2.06 719 2.39
5250 537 1.43 592 1.73 643 2.03 691 2.35 737 2.69
5625 566 1.71 619 2.03 667 2.35 713 2.68 757 3.03
6000 596 2.02 646 2.36 692 2.70 736 3.05 778 3.41
6375 625 2.36 674 2.73 718 3.09 760 3.46 800 3.83
6750 655 2.75 701 3.14 744 3.52 785 3.91 824 4.30
7125 685 3.17 729 3.58 771 3.99 810 4.40 848 4.81
7500 715 3.64 758 4.07 798 4.50 836 4.93 872 5.36
CFM
Available External Static Pressure (in. wg)
1.2 1.4 1.6 1.8 2.0
RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
4500 755 2.48 805 2.87 853 3.28 900 3.72 945 4.17
4875 768 2.75 815 3.14 862 3.55 907 3.99 951 4.45
5250 783 3.06 828 3.45 872 3.86 916 4.30 958 4.77
5625 800 3.40 843 3.80 885 4.21 926 4.66 967 5.12
6000 819 3.79 860 4.19 900 4.61 939 5.06 978 5.53
6375 840 4.23 878 4.63 916 5.06 954 5.51 991 5.98
6750 861 4.70 898 5.12 935 5.56 971 6.01 --- --- --- --- --- --- --- ---
7125 884 5.23 919 5.66 --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- ---
7500 907 5.79 --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- ---
NOTE: For more information, see General Fan Performance Notes.
Boldface indicates field supplied drive is required.
