12
Table 7 – PHYSICAL DATA (COOLING) 3 -- 6 TONS
580J*04A 580J*05A 580J*06A 580J*07A
Refrigeration System
#Circuits/#Comp./Type 1/1/Scroll 1/1/Scroll 1/1/Scroll 1/1/Scroll
Puronr refrig. (R---410A) (lbs--- oz) 5 --- 1 0 8 --- 8 10--- 11 1 4 --- 2
O p e r a t i n g c h a r g e ( l b s --- o z ) --- P e r f e c t H u m i d i t y U n i t 8 --- 1 1 14---13 1 6 --- 0 2 2 --- 5
Metering Device Acutrol Acutrol Acutrol Acutrol
High---press. Trip / Reset (psig) 630 / 505 630 / 505 630 / 505 630 / 505
Low--- press. Trip / Reset (psig) 54 / 117 54 / 117 54 / 117 54 / 117
Compressor Capacity Staging (%) 100% 100% 100% 100%
Evap. Coil
Material (Tube/Fin) C u / Al Cu / Al Cu / Al Cu / Al
Coil type 3/8--- in RTPF 3 / 8 --- i n R T P F 3 / 8 --- i n R T P F 3 / 8 --- i n R T P F
Rows / FPI 2 / 15 2/15 4/15 4/15
Tota l Fa c e A r ea ( f t
2
)5.5 5.5 5.5 7.3
Condensate Drain Conn. Size 3/4--- in 3 / 4 --- i n 3 / 4 --- i n 3 / 4 --- i n
Evap. Fan and Motor
Standard Static
1phase
Motor Qty / Drive Type 1/Belt
1/Belt 1/Belt ---
Max BHP 1.2
1.2 1.2 ---
RPM Range 560---854 560---854 770--- 1175 ---
Motor Frame Size 48 48 48 ---
Fan Qty / T ype 1/Centrifugal 1/Centrifugal 1/Centrifugal ---
Fan Diameter (in) 10 x 10 10 x 10 10 x 10 ---
Medium Static
1phase
Motor Qty / Drive Type 1/Belt 1/Belt 1/Belt ---
Max BHP 1.2 1.2 1.5 ---
RPM Range 770---1175 770--- 1175 1035---1466 ---
Motor Frame Size 48 48 56 ---
Fan Qty / T ype 1/Centrifugal 1/Centrifugal 1/Centrifugal ---
Fan Diameter (in) 10 x 10 10 x 10 10 x 10 ---
Standard Static
3phase
Motor Qty / Drive Type 1/Belt 1/Belt 1/Belt 1/Belt
Max BHP 1.2 1.2 1.5 2.4
RPM Range 560---854 560---854 770--- 1175 1073--- 1457
Motor Frame Size 48 48 48 56
Fan Qty / T ype 1/Centrifugal 1/Centrifugal 1/Centrifugal 1/Centrifugal
Fan Diameter (in) 10 x 10 10 x 10 10 x 10 10 x 10
Medium Static
3phase
Motor Qty / Drive Type 1/Belt 1/Belt 1/Belt 1/Belt
Max BHP 1.2 1.2 2.4 2.9*
RPM Range 770---1175 770--- 1175 1035---1466 1173---1518
Motor Frame Size 48 48 56 56
Fan Qty / T ype 1/Centrifugal 1/Centrifugal 1/Centrifugal 1/Centrifugal
Fan Diameter (in) 10 x 10 10 x 10 10 x 10 10 x 10
High Static
3phase
Motor Qty / Drive Type 1/Belt 1/Belt 1/Belt 1/Belt
Max BHP 2.4 2.4 2.9 3.7
RPM Range 1035---1466 1035--- 1466 1303--- 1687 1474--- 1788
Motor Frame Size 56 56 56 56
Fan Qty / T ype 1/Centrifugal 1/Centrifugal 1/Centrifugal 1/Centrifugal
Fan Diameter (in) 10 x 10 10 x 10 10 x 10 10 x 10
Cond. Coil
Material (Tube/Fin) C u / Al Cu / Al Cu / Al Cu / Al
Coil type 3/8--- in RTPF 3 / 8 --- i n R T P F 3 / 8 --- i n R T P F 3 / 8 --- i n R T P F
Rows / FPI 1 / 17 2/17 2/17 2/17
Tota l Fa c e A r ea ( f t
2
) 14.6 16.5 16.5 21.3
Perfect Humidity Coil
Material (Tube/Fin) C u / Al Cu / Al Cu / Al Cu / Al
Rows..Fins/in. 1 / 17 2/17 2/17 2/17
Tota l Fa c e A r ea ( f t
2
)3.9 3.9 3.9 5.2
Cond. fan / motor
Qty / Motor Drive Type 1/ Direct 1/ Direct 1/ Direct 1/ Direct
Motor HP / RPM 1/4 / 1100 1/4 / 1100 1/4 / 1100 1/4 / 1100
Fan diameter (in) 22 22 22 22
Filters
RA Filter # / Size (in) 2 / 16 x 25 x 2 2/16x25x2 2/16x25x2 4/16x16x2
OA inlet screen # / Size (in) 1/20x24x1 1/20x24x1 1/20x24x1 1/20x24x1
NOTE: Perfect Humidity is not available with Novation condenser coil models. Only Round Tube / Plate Fin (RTPF).
* 575V motor utilizes 3.7 BHP.
