Table 71 – MCA/MOCP DETERMINATION NO C.O. OR UNPWRD C.O.
UNIT
NOM.
V --- P h --- H z
IFM
TYPE
COMBUSTION
FAN MOTOR
FLA
POWER
EXHAUST
FLA
NO C.O. or UNPWRD C.O.
NO P.E. w/ P.E. (pwrd fr/ unit)
MCA MOCP
DISC. SIZE
MCA MOCP
DISC. SIZE
FLA LRA FLA LRA
580J*04A
208/230--- 1--- 60
STD
0.48 1.9
27.2 40.0 26 95 29.1 45.0 29 97
MED 27.2 40.0 26 95 29.1 45.0 29 97
208/230--- 3--- 60
STD
0.48 1.9
19.4 25.0 19 89 21.3 30.0 22 91
MED 19.4 25.0 19 89 21.3 30.0 22 91
HIGH 19.7 30.0 20 107 21.6 30.0 22 109
4 6 0 --- 3 --- 6 0
STD
0.25 1.0
10.2 15.0 10 46 11.2 15.0 11 47
MED 10.2 15.0 10 46 11.2 15.0 11 47
HIGH 10.7 15.0 11 55 11.7 15.0 12 56
5 7 5 --- 3 --- 6 0
STD
0.24 1.9
7.3 15.0 7 44 9.2 15.0 9 46
MED 7.3 15.0 7 44 9.2 15.0 9 46
HIGH 7.4 15.0 7 50 9.3 15.0 10 52
580J*05A
208/230--- 1--- 60
STD
0.48 1.9
33.7 50.0 32 133 35.6 50.0 35 135
MED 33.7 50.0 32 133 35.6 50.0 35 135
208/230--- 3--- 60
STD
0.48 1.9
23.5 30.0 23 99 25.4 30.0 25 101
MED 23.5 30.0 23 99 25.4 30.0 25 101
HIGH 23.8 30.0 23 117 25.7 30.0 25 119
4 6 0 --- 3 --- 6 0
STD
0.25 1.0
10.7 15.0 10 49 11.7 15.0 12 50
MED 10.7 15.0 10 49 11.7 15.0 12 50
HIGH 11.2 15.0 11 58 12.2 15.0 12 59
5 7 5 --- 3 --- 6 0
STD
0.24 1.9
8.5 15.0 8 44 10.4 15.0 11 46
MED 8.5 15.0 8 44 10.4 15.0 11 46
HIGH 8.6 15.0 9 50 10.5 15.0 11 52
580J*06A
208/230--- 1--- 60
STD
0.48 1.9
39.2 60.0 37 150 41.1 60.0 40 152
MED 41.3 60.0 40 175 43.2 60.0 42 177
208/230--- 3--- 60
STD
0.48 1.9
25.9 30.0 25 126 27.8 40.0 27 128
MED 26.2 40.0 26 144 28.1 40.0 28 146
HIGH 28.5 40.0 29 170 30.4 45.0 30 172
4 6 0 --- 3 --- 6 0
STD
0.25 1.0
12.5 20.0 12 60 13.5 20.0 13 61
MED 13.0 20.0 13 69 14.0 20.0 14 70
HIGH 13.8 20.0 14 82 14.8 20.0 15 83
5 7 5 --- 3 --- 6 0
STD
0.24 1.9
9.8 15.0 10 46 11.7 15.0 12 48
MED 9.9 15.0 10 52 11.8 15.0 13 54
HIGH 10.7 15.0 11 63 12.6 15.0 13 65
580J*07A
208/230--- 3--- 60
STD
0.48 1.9
30.5 45 30 157 32.4 50 32 159
MED 32.8 50 32 183 34.7 50 34 185
HIGH 32.8 50 32 183 34.7 50 34 185
4 6 0 --- 3 --- 6 0
STD
0.25 1.0
15.5 25 15 79 16.5 25 16 80
MED 16.3 25 16 92 17.3 25 17 93
HIGH 17.3 25 17 101 18.3 25 18 102
5 7 5 --- 3 --- 6 0
STD
0.24 1.9
11.9 15 12 63 13.8 20 14 65
MED 12.7 20 12 74 14.6 20 15 76
HIGH 12.7 20 12 74 14.6 20 15 76
580J*08A
208/230--- 3--- 60
STD
0.48 3.8
39.5 60 38 191 43.3 60 43 195
MED 41.8 60 41 228 45.6 60 45 232
HIGH 49.3 60 49 254 53.1 60 54 258
4 6 0 --- 3 --- 6 0
STD
0.25 1.8
19.5 30 19 113 21.3 30 21 115
MED 20.3 30 20 132 22.1 30 22 134
HIGH 24.3 30 24 145 26.1 30 26 147
5 7 5 --- 3 --- 6 0
STD
0.24 3.8
14.9 20 14 89 18.7 25 19 93
MED 15.3 20 15 104 19.1 25 19 108
HIGH 18.1 25 18 118 21.9 30 23 122
