71
ELECTRICAL INFORMATION (cont.)
Table 65 – 580J*09A 1--Stage Cooling 8.5 TONS
V --- P h --- H z
VOLTAGE
RANGE
COMP (ea) OFM (ea) IFM
RLA LRA WATTS FLA TYPE EFF at Full Load FLA
MIN MAX
2 0 8 --- 3 --- 6 0 187 253 29.5 195 325 1.5
Std Static 80% 5.2
Med Static 80% 5.2
High Static 80% 10.0
2 3 0 --- 3 --- 6 0 187 253 29.5 195 325 1.5
Std Static 80% 5.2
Med Static 80% 5.2
High Static 80% 10.0
4 6 0 --- 3 --- 6 0 414 506 14.7 95 325 0.8
Std Static 80% 2.6
Med Static 80% 2.6
High Static 80% 4.4
5 7 5 --- 3 --- 6 0 518 633 12.2 80 325 0.6
Std Static 80% 2.4
Med Static 80% 2.0
High Static 81% 2.8
Table 66 – 580J*09D 2--Stage Cooling 8.5 TONS
V --- P h --- H z
VOLTAGE
RANGE
COMP (Cir 1) COMP (Cir 2) OFM (ea) IFM
RLA LRA RLA LRA WATTS FLA TYPE
EFF at
Full Load
FLA
MIN MAX
2 0 8 --- 3 --- 6 0 187 253 14.5 98 13.7 83 325 1.5
STD 80% 5.2
MED 80% 5.2
HIGH 80% 10.0
2 3 0 --- 3 --- 6 0 187 253 14.5 98 13.7 83 325 1.5
STD 80% 5.2
MED 80% 5.2
HIGH 80% 10.0
4 6 0 --- 3 --- 6 0 414 506 6.3 55 6.2 41 325 0.8
STD 80% 2.6
MED 80% 2.6
HIGH 80% 4.4
5 7 5 --- 3 --- 6 0 518 633 6.0 41 4.8 33 325 0.6
STD 80% 2.4
MED 80% 2.0
HIGH 81% 2.8
Table 67 – 580J*12A 1--Stage Cooling 10 TONS
V --- P h --- H z
VOLTAGE
RANGE
COMP (ea) OFM (ea) IFM
RLA LRA WATTS FLA TYPE
EFF at Full
Load
FLA
MIN MAX
2 0 8 --- 3 --- 6 0 187 253 30.1 225 325 1.5
Std Static 80% 5.2
Med Static 81% 10.0
High Static 81% 15.0
2 3 0 --- 3 --- 6 0 187 253 30.1 225 325 1.5
Std Static 80% 5.2
Med Static 81% 10.0
High Static 81% 15.0
4 6 0 --- 3 --- 6 0 414 506 16.7 114 325 0.8
Std Static 80% 2.6
Med Static 81% 4.4
High Static 81% 7.4
5 7 5 --- 3 --- 6 0 518 633 12.2 80 325 0.6
Std Static 80% 2.0
Med Static 81% 2.8
High Static 81% 5.6
