Bryant LEGACY 580J User Manual

14
Table 9 – PHYSICAL DATA (COOLING) 7.5 -- 8.5 TONS
580J*08A 580J*08D 580J*09A 580J*09D
Refrigeration System
# Circuits / # Comp. / Type 1/1/Scroll 2/2/Scroll 1/1/Scroll 2/2/Scroll
RTPF models R--- 410a charge A/B (lbs --- oz) 1 3 --- 1 2 / --- 8 --- 5 / 8 --- 2 1 5 --- 4 / --- 1 0 --- 5 / 1 0 --- 1 2
Alternate (MCHX) R--- 410a charge A/B (lbs --- oz) --- 4 --- 6 / 4 --- 6 --- ---
Alternate (Perfect Humidity) R---410a charge A/B (lbs --- oz) --- 1 3 --- 3 / 1 3 --- 3 --- 1 6 --- 1 3 / 1 6 --- 1 3
Metering device Accutrol Accutrol Accutrol Accutrol
High---press. Trip / Reset (psig) 630 / 505 630 / 505 630 / 505 630 / 505
Low--- press. Trip / Reset (psig) 54 / 117 54 / 117 54 / 117 54 / 117
Loss of charge Trip / Reset (psig) --- --- --- ---
Evap. Coil
Material Cu / Al Cu / Al Cu / Al Cu / Al
Coil type 3/8” RTPF 3/8” RTPF 3/8” RTPF 3/8” RTPF
Rows / FPI 3/15 3/15 3/15 3/15
total face area (ft
2
) 8.9 8.9 11.1 11.1
Condensate drain conn. size 3/4” 3/4” 3/4” 3/4”
Perfect Humidity Coil
Material --- Cu / Al --- Cu / Al
Coil type --- 3/8” RTPF --- 3/8” RTPF
Rows / FPI --- 2/17 --- 2/17
total face area (ft
2
) --- 6.3 --- 8.4
Evap. fan and motor
Standard Static
3 phase
Motor Qty / Drive type 1/Belt 1/Belt 1/Belt 1/Belt
Max BHP 1.7 1.7 1.7 1.7
RPM range 489--- 747 489---747 518--- 733 518--- 733
motor frame size 56 56 56 56
Fan Qty / T ype 1/Centrifugal 1/Centrifugal 1/Centrifugal 1/Centrifugal
Fan Diameter (in) 15 x 15 15 x 15 15 x 15 15 x 15
Medium Static
3 phase
Motor Qty / Drive type 1/Belt 1/Belt 1/Belt 1/Belt
Max BHP 2.9 2.9 2.4 2.4
RPM range 733--- 949 733---949 690--- 936 690--- 936
motor frame size 56 56 56 56
Fan Qty / T ype 1/Centrifugal 1/Centrifugal 1/Centrifugal 1/Centrifugal
Fan Diameter (in) 15 x 15 15 x 15 15 x 15 15 x 15
High Static
3 phase
Motor Qty / Drive type 1/Belt 1/Belt 1/Belt 1/Belt
Max BHP 4.7 4.7 3.7 3.7
RPM range 909--- 1102 909---1102 838--- 1084 838---1084
motor frame size 14 14 56 56
Fan Qty / T ype 1/Centrifugal 1/Centrifugal 1/Centrifugal 1/Centrifugal
Fan Diameter (in) 15 x 15 15 x 15 15 x 15 15 x 15
Cond. Coil
Material Cu / Al Cu / Al Cu / Al Cu / Al
Coil type 3/8” RTPF 3/8” RTPF 3/8” RTPF 3/8” RTPF
Rows / FPI 2/17 2/17 2/17 2/17
total face area (ft2) 20.5 20.5 21.4 25.1
Alternate (MCHX) Cond . Coil ---
Material --- Al / Al --- ---
Coil type --- Novation™ --- ---
Rows / FPI --- 1/20 --- ---
total face area (ft2) --- 20.5 --- ---
Cond. fan / motor
Qty / Motor drive type 2/direct 2/direct 2/direct 2/direct
Motor HP / RPM 1/4 / 1100 1/4 / 1100 1/4 / 1100 1/4 / 1100
Fan diameter (in) 22 22 22 22
Filters
RAFilter#/Size(in) 4/16x20x2 4/16x20x2 4/20x20x2 4/20x20x2
OA inlet screen # / Size (in) 1/20x24x1 1/20x24x1 1/20x24x1 1/20x24x1
NOTE: Perfect Humidity is not available with Novation condenser coil models. Only Round Tube/Plate Fin (RTPF).
