Bryant LEGACY 580J User Manual

15
Table 10 – PHYSICAL DATA (HEATING) 7.5 -- 8.5 TONS
580J**08 580J**09
Gas Connection
#ofGasValves 1 1
Nat. gas supply line press (in. w.g.) / (PSIG) 4 --- 1 3 / 0 . 1 8 --- 0 . 4 7 4 --- 1 3 / 0 . 1 8 --- 0 . 4 7
LP supply line press (in. w.g.) / (PSIG) 11 --- 13 / 0.40 --- 0.47 11 --- 13 / 0.40 --- 0.47
Heat Anticipator setting (Amps)
1st stage 0.14 0.14
2nd stage 0.14 0.14
Natural Gas Heat
LOW
#ofstages/#ofburners(total) 1/3 1/3
Connection Size 1/2” NPT 1/2” NPT
Rollout switch opens / closes 195 / 115 195 / 115
Temp erat u r e R ise 20 --- 50 20 --- 50
MED
#ofstages/#ofburners(total) 2/4 2/4
Connection Size 3/4” NPT 3/4” NPT
Rollout switch opens / closes 195 / 115 195 / 115
Temp erat u r e R ise 35 --- 65 30 --- 65
HIGH
#ofstages/#ofburners(total) 2/5 2/5
Connection Size 3/4” NPT 3/4” NPT
Rollout switch opens / closes 195 / 115 195 / 115
Temp erat u r e R ise 45 --- 75 40 --- 75
Liquid Propane Heat
LOW
#ofstages/#ofburners(total) 1/3 1/3
Connection Size 1/2” NPT 1/2” NPT
Rollout switch opens / closes 195 / 115 195 / 115
Temp erat u r e R ise 20 --- 50 20 --- 50
MED
#ofstages/#ofburners(total) 2/4 2/4
Connection Size 3/4” NPT 3/4” NPT
Rollout switch opens / closes 195 / 115 195 / 115
Temp erat u r e R ise 35 --- 65 30 --- 65
HIGH
#ofstages/#ofburners(total) 2/5 2/5
Connection Size 3/4” NPT 3/4” NPT
Rollout switch opens / closes 195 / 115 195 / 115
Temp erat u r e R ise 45 --- 75 40 --- 75
Low NOx Gas Heat
LOW
#ofstages/#ofburners(total) --- ---
Connection Size --- ---
Rollout switch opens / closes --- ---
Temp erat u r e R ise --- ---
MED
#ofstages/#ofburners(total) --- ---
Connection Size --- ---
Rollout switch opens / closes --- ---
Temp erat u r e R ise --- ---
HIGH
#ofstages/#ofburners(total) --- ---
Connection Size --- ---
Rollout switch opens / closes --- ---
Temp erat u r e R ise --- ---
