Bryant LEGACY 580J User Manual

16
Table 11 – PHYSICAL DATA (COOLING) 10 -- 15 TONS
580J*12A 580J*12D 580J*14D 580J*16D
Refrigeration System
# Circuits / # Comp. / T ype 1/1/Scroll 2/2/Scroll 2/2/Scroll 2/2/Scroll
RTPF models R---410a char ge A/B (lbs --- oz) 2 0 --- 0 10 --- 5 / 1 0 --- 3 1 1 --- 0 / 1 1 --- 6 15 --- 1 4 / 1 6 --- 1 2
Alternate (MCHX) R---410a charge A/B (lbs --- oz) --- 6 --- 0 / 6 --- 0 7 --- 6 / 8 --- 0 ---
Alternate (Perfect Humidity) R---410a char ge A/B (lbs --- oz) --- 1 6 --- 1 0 / 1 6 --- 0 1 7 --- 1 0 / 1 8 --- 3 ---
Metering device Accutrol Accutrol A ccutrol Accutrol
High---press. Trip / Reset (psig) 630 / 505 630 / 505 630 / 505 630 / 505
Low---press. Trip / Reset (psig) 54 / 117 54 / 117 54 / 117 54 / 117
Loss of charge Tr ip / Reset (psig) --- --- --- ---
Evap. Coil
Material Cu / Al Cu / Al Cu / Al Cu / Al
Coil type 3/8” RTPF 3/8” RTPF 3/8” RTPF 3/8” RTPF
Rows / FPI 4/15 4/15 4/15 3/15
total face area (ft
2
) 11.1 11.1 11.1 17.5
Condensate drain conn. size 3/4” 3/4” 3/4” 3/4”
Perfect Humidity Coil
Material --- Cu / Al Cu / Al ---
Coil type --- 3/8” RTPF 3/8” RTPF ---
Rows / FPI --- 2/17 2/17 ---
total face area (ft
2
) --- 8.4 8.4 ---
Evap. f an and motor
Standard Static
3 phase
Motor Qty / Drive type 1/Belt 1/Belt 1/Belt 1/Belt
Max BHP 2.4 2.4 2.9 2.9
RPM range 591---838 591---838 652---843 507---676
motor frame size 56 56 56 56
Fan Qty / T ype 1/Centrifugal 1/Centrifugal 1/Centrifugal 1/Centrifugal
Fan Diameter (in) 15 x 15 15 x 15 15 x 15 18 x 18
Medium Static
3 phase
Motor Qty / Drive type 1/Belt 1/Belt 1/Belt 1/Belt
Max BHP 3.7 3.7 3.7 3.7
RPM range 838 ---1084 838 ---1084 838 ---1084 627 ---851
motor frame size 56 56 56 56
Fan Qty / T ype 1/Centrifugal 1/Centrifugal 1/Centrifugal 1/Centrifugal
Fan Diameter (in) 15 x 15 15 x 15 15 x 15 18 x 18
High Static
3 phase
Motor Qty / Drive type 1/Belt 1/Belt 1/Belt 1/Belt
Max BHP 4.7 4.7 4.7 6.1
RPM range 1022---1240 1022 ---1240 1022 ---1240 776 ---955
motor frame size 14 14 14 S184T
Fan Qty / T ype 1/Centrifugal 1/Centrifugal 1/Centrifugal 1/Centrifugal
Fan Diameter (in) 15 x 15 15 x 15 15 x 15 18 x 18
High Static
-- H i g h
Efficiency
3 phase*
Motor Qty / Drive type 1/Belt
Max BHP 6.1
RPM range 776 ---955
motor frame size S184T
Fan Qty / T ype 1/Centrifugal
Fan Diameter (in) 15 x 15 18 x 18
Cond. Coil
Material Cu / Al Cu / Al Cu / Al Cu / Al
Coil type 3/8” RTPF 3/8” RTPF 3/8” RTPF 3/8” RTPF
Rows / FPI 2/17 2/17 3/17 2/17
total face area (ft2) 25.1 25.1 25.1 2 @ 23.1
Alternate (MCHX) Cond. Coil
Material --- Al / Al Al / Al ---
Coil type --- Nova tion™ Novation™ ---
Rows / FPI --- 1/20 2/20 ---
total face area (ft2) --- 25.1 25.1 ---
Cond. fan / motor
Qty / Motor drive type 2/direct 2/direct 1/direct 3/direct
Motor HP / RPM 1/4 / 1100 1/4 / 1100 1 / 1175 1/4 / 1100
Fan diameter (in) 22 22 30 22
Filters
RAFilter#/Size(in) 4/20x20x2 4/20x20x2 4/20x20x2 16 / 18 x 24 x 2
V2 / 24 x 27 x 1
OA inlet screen # / Size (in) 1/20x24x1 1/20x24x1 1/20x24x1 H1 / 30 x 39 x 1
NOTE: Perfect Humidity is not available with Novation condenser coil models. Only Round Tube/Plate Fin (RTPF) up to 14 size.
* Section 313 of the Energy Independence a nd Security Act of 2007 (EISA 2007) mandates that the efficiency of general purpose motors we use in our Light
Commercial Rooftops rated at 5.0HP and larger be increased on or after December 19, 2010. We will offer both high and standard efficient motors until
inventory is depleted and then shift over solely to the high efficient motors only.
