Bryce 30K - Service Menu

Revision C 30K USERS MANUAL Section A - 5
P/N 90-00203-001
Appendix A • Bryce Office Systems 30K SERVICE MENU Flow Chart
---SERVICE MENU---
1. Adjust Print
BANK A
Head 2 up down
MOVE HD 2 VERT +UP
*294 press test -DOWN
BANK A
Head 3 up down
MOVE HD 3 VERT +UP
*294 press test -DOWN
BANK B
Head 5 up down
MOVE HD 5 VERT +UP
*294 press test -DOWN
BANK B
Head 6 up down
MOVE HD 6 VERT +UP
*294 press test -DOWN
BANK A
Head 2 side to side
MOVE HD 2 <-> +LEFT
*50 press test -RIGHT
BANK A
Head 3 side to side
MOVE HD 3 <-> +LEFT
*50 press test -RIGHT
BANK B
Head 5 side to side
MOVE HD 5 <-> +LEFT
*50 press test -RIGHT
BANK B
Head 6 side to side
MOVE HD 6 <-> +LEFT
*50 press test -RIGHT
MOVE BANK A <-> +LEFT
* 01.000” test -RGHT
MOVE BANK B <-> +LEFT
* 07.500” test -RGHT
---SERVICE MENU---
2. Test System
debug *BELT 00 ips
p F FEEDER 00 ips
---SERVICE MENU---
3. Test Display
abcdefghijklmnopqrst
ABCDEFGHIJKLMNOPQRST
scrolls for 3
seconds then stops
