28/67 ekr 500 digital Unit Touch – CANopen User Gateway

Index Short Description Sub-

Index

Object Data Type Access

4aa2h

Sensor positioner –

Setting the positioning speed

of the sensor slides during

automatic edge detection

00h

Sensor positioner –

Positioning speed during edge

detection

Unsigned32 rw

4aa3h

Sensor positioner –

Setting the positioning speed

of the sensor slides during

web guiding

00h

Sensor positioner –

Positioning speed during web

guiding

Unsigned32 rw

4aa4h

Sensor positioner –

Setting the positioning speed

of the sensor slides during

retraction

00h

Sensor positioner –

Positioning speed during retraction

Unsigned32 rw

4ac0h

Wide array edge sensor –

Activating the general setpoint

transfer

00h

Wide array edge sensor –

Setpoint transfer, generally

Unsigned8 rw

4ac1h

Wide array edge sensor –

Activating the setpoint transfer

for web edge guiding to edge1

00h

Wide array edge sensor –

Setpoint transfer edge1

Unsigned8 rw

4ac2h

Wide array edge sensor –

Activating the setpoint transfer

for web edge guiding to edge2

00h

Wide array edge sensor –

Setpoint transfer edge2

Unsigned8 rw

4ac3h

Wide array edge sensor –

Activating the setpoint transfer

for web center-line guiding

00h

Wide array edge sensor –

Setpoint transfer center1&2

Unsigned32 rw

4ad1h

Sensor positioner –

Setting the position offsets for

the sensor slides

00h Number of sub-indexes Unsigned8 ro

01h Position offset sensor slide1 Signed32 rw

02h Position offset sensor slide2 Signed32 rw

6401h

Reading the standardized

values of the analogue

controller inputs

00h Number of sub-indexes Unsigned8 ro

01h Reserved — —

02h

Input value of the servo center

transducer (SC)

Signed16 ro

03h

…

23h

Reserved — —
