BST ekr 500 digital Unit Touch Translation Of The Original Manual

4
Protocol 3100
58/67 ekr 500 digital Unit Touch – CANopen User Gateway
4.2.2.24 Object 4ac0h: Wide Array Edge Sensor – Setpoint Transfer, Generally
Index 4ac1h
Name Wide array edge sensor –
Setpoint transfer, generally
Function Activating the general setpoint transfer for wide
array edge sensors
Object Code Var
Data Type Unsigned8
Value Description
Sub-Index 00h
Description Activation of the general setpoint transfer
Object Class Mandatory
Access Rw
PDO Mapping No
Unit —
Value Range 0: Setpoint transfer disabled
1: Setpoint transfer enabled
4.2.2.25 Object 4ac1h: Wide Array Edge Sensor – Setpoint Transfer Edge1
Index 4ac1h
Name Wide array edge sensor –
Setpoint transfer edge1
Function Activating the setpoint transfer for web edge
guiding (guiding to edge1).
The current web edge position is taken over as
setpoint for edge1.
Object Code Var
Data Type Unsigned8
Value Description
Sub-Index 00h
Description
- Activation of the setpoint transfer for edge1
Object Class Mandatory
Access Rw
PDO Mapping No
Unit —
Value Range 0: Setpoint transfer disabled
1: Setpoint transfer enabled
