BST ekr 500 digital Unit Touch Translation Of The Original Manual

4
Protocol 3100
60/67 ekr 500 digital Unit Touch – CANopen User Gateway
4.2.2.27 Object 4ac3h: Wide Array Edge Sensor – Setpoint Transfer Center1&2
Index 4ac3h
Name Wide array edge sensor –
Setpoint transfer Center1&2
Function Activating the setpoint transfer for web center-
line guiding (guiding to center1&2).
The current web edge positions are taken over
as setpoints for web center-line guiding.
Object Code Var
Data Type Unsigned32
Value Description
Sub-Index 00h
Description
- Activation of the setpoint transfer
for center1&2
Object Class Mandatory
Access Rw
PDO Mapping No
Unit —
Value Range 0: Setpoint transfer disabled
1: Setpoint transfer enabled
