ekr 500 digital Unit Touch – CANopen User Gateway 61/67
4.2.2.28 Object 4ad1h: Sensor Positioner – Position Offsets
With the position offset, you can create a reference system with
an absolute reference point for the position of the sensor slides.
This reference point can be a distinctive point on the machine
(e.g. machine wall or center of the machine). As an alternative,
you can also use the park position of a sensor slide or the middle
of the sensor positioner as reference point. The set offset value
(position offset) is added to the current position of the sensor
slide in the controller and then results in the absolute distance to
the reference point selected.
The procedure for adjusting the position offsets is described in the
installation and commissioning manual of the ekr 500 digital Unit
Touch controller (document number MD.497).
Index 4ad1h
Name Sensor positioner – Position offsets
Function Setting the position offsets for the sensor slides
Object Code Array
Data Type Signed32
Value Description
Sub-Index 00h
Description Number of sub-indexes
Object Class Mandatory
Access Ro
Value 2
Sub-Index 01h
Description Position offset sensor slide1
Object Class Mandatory
Access Rw
PDO Mapping Non
Unit µm
Value Range Depending on the application
Sub-Index 02h
Description Position offset sensor slide2
Object Class Mandatory
Access Rw
PDO Mapping No
Unit µm
Value Range Depending on the application
