Electrical Connection

ekr 500 digital Unit Touch – Master-Slave Guiding with Sensor Positioner 15/45

5.3 Connector Assignment

The assignment of the connectors at the ekr 500 digital Unit Touch

controller housing depends on the number of edge sensors used

for the Master-Slave Guiding.

5.3.1 Master-Slave Guiding with Two Edge Sensors

5.3.1.1 Guiding to the Left Web Edge

Fig.2: Connector assignment on the controller

Connector Assignment

Component Web of Material Connector

ekrcommander X101

Sensor1 SLAVE web X102

Sensor3 MASTER web X100
