Ex 2. Programming a Channel Repeater Offset with CTCSS Tone
from MR Mode (Using Direct Frequency Entry)
New memory in Channel 10:
RX = 432.55000 MHz
TX = 437.55000 MHz (This is a (+ 5) Offset)
TX CTCSS tone 123.0
1. Press the key to switch between menus.
2. Press V/M key to set the radio to MR mode, and the VFO icon
is not displayed.
3. Enter RX frequency (Ex. 43255000)
Enter RX frequency (Ex. 43255000)
4. [5] [1][7] [1][0]
Deletes Prior Data in channel (Ex. 10)
5. [5] [6] 123.0
Selects desired RX encode tone (Ex 123 CTCSS)
6. [5] [8] 123.0
Selects desired TX encode tone (Ex 123 CTCSS)
7. [5] [2] 43255000
Enter RX frequency (Ex. 432.55000)
8. [5] [3] 43755000
Enter TX frequency (Ex. 437.55000)
9. [6] [1][6] [1][0]
Enter the same channel (Ex 10)
-->>
Channel has been added
10. Return to the MR mode and the channel number will reappear.
