Ex 1. Programming a Channel Repeater Offset with CTCSS Tone
from VFO Mode (Using Offset Menu)
New memory in Channel 10:
RX = 432.55000 MHz
TX = 437.55000 MHz (This is a (+ 5) Offset)
TX CTCSS tone 123.0
1. Press the key to switch between menus.
2. Press V/M key to set the radio to VFO mode, and the VFO icon is
displayed.
3. Enter RX frequency (Ex. 43255000)
Enter RX frequency (Ex. 432.55000)
4. [5] [1] [5] [1] [0]
Deletes Prior Data in channel (Ex. 10)
5. [5] [4] 123.0
Selects desired RX encode tone (Ex 123 CTCSS)
6. [5] [6] 123.0
Selects desired TX encode tone (Ex 123 CTCSS)
7. [5] [1] [2] [0] [0] [5] [0] [0]
Enter the Offset frequency (Ex. 5.00MHz)
8. [6] [1][3] [Plus]
Select the Offset direction (Ex. plus Offset)
9. [6] [1][4] [1][0]
Enter the same channel (Ex 10)
-->>
Channel has been added
10. Press V/M key to return to the MR mode and the channel number
will reappear.
