VISIT BAOFENGTECH.COM AND MIKLOR.COM FOR DOWNLOADS AND HELP
1. Power, On/Off Press + Volume Knob
2. V/M Mode Switch (Channel/Frequency)
3. Confirm Key Press +Main Selector
(Menu Knob)
4. Monitor function
5. FM radio function key
6. Display screen
7. Call key
8. Exit Menu + A/B/C/D signal switching +
alarm function
9. High/Mid/Low Power Switch + Lock
10. Microphone Connector
11. DATA, Programming Jack: PC-04
Programming Cable Jack
: when in standby, press to send caller ID
(ANI) in the selected signaling mode; while
transmitting, press to send activate signaling.
: press to turn on the squelch, repeat to
turn off the squelch.
: press to switch between channel mode
and frequency mode.
: press to choose between A, B, C, or D
frequencies --- Or exit function mode.
: press to enter and exit FM radio
: press to toggle high/mid/low power;
hold to key-lock/or key-unlock
RJ45!Connector:!
