Controls and MEC2 programming unit
5
Logamatic 4121, 4122 and 4126 - Subject to technical modifications.
14
Fig. 5 Fitted modules (example: Logamatic 4121)
1 Slot 1 for ZM424 module, comprising:
2 Heating circ 1 – mixed
alternative: Heating circ 1 – unmixed + DHW and DHW circulation
3 Heating circ 2 – mixed
4 Slot A for FM455 module KSE1
5 Slot 2 for an additional module
6 MEC2
7 CM431
USER INFORMATION
For the Logamatic 4126 control unit, the
FM445 module is installed in slot 1 (DHW
via primary system) (Æ
Chapter 9.4).
