Operation with the user menu
Logamatic EMS RC35 programming unit - Subject to technical modifications
24
5
4. Press to confirm the selection.
The USER\OPERATING MODE menu is opened.
The appearance of the display depends on the number of
heating circuits. If there is only one heating circuit installed
with no DHW and no DHW circulation pump, this screen will
not appear at all (Æ page 26).
Continue to the next step.
5. Press to select heating circuit 1.
6. To change the value, hold down (the value
starts flashing) and turn rotary selector at the same
time.
7. Release .
The value stops flashing. The modified value is saved.
8. If you have carried out this example as practice only, make
sure that the original setting is retained.
To do so, repeat steps 6 and 7 if necessary.
Operation Result
Tab. 8 How to use the user menu (example)
heating circuit 1
heating circuit 2
heating circuit 3
domestic hot water
USER\OPERATING MODE
Which operation mode
should be used?
OPERATING MODE\HC 1
automatic operation
Which operation mode
should be used?
OPERATING MODE\HC 1
automatic operation
Which operation mode
should be used?
OPERATING MODE\HC 1
continuous heating
Which operation mode
should be used?
OPERATING MODE\HC 1
automatic operation

Buderus RC35 Specifications

General

Display	LCD
Temperature Control	Yes
Weather Compensation	Yes
Communication	EMS Bus
Mounting	Wall-mounted
Voltage	24 V
Temperature range	5°C to 30°C
Accuracy	±0.5°C
Protection class	IP20
Weight	0.3 kg
Power consumption	2 W
Switching current	Not applicable
Ambient temperature	0°C to 45°C
