Explanation of symbols and safety instructions
Logamatic EMS RC35 programming unit - Subject to technical modifications
6
1
1 Explanation of symbols and safety instructions
1.1 Explanation of symbols
Warning symbols
Signal words indicate the seriousness of the hazard in terms of the consequences of not following
the safety instructions.
• NOTICE indicates possible damage to property or equipment, but where there is no risk of injury.
• CAUTION indicates possible injury.
• WARNING indicates possible severe injury.
• DANGER indicates possible risk to life.
Important information
Additional symbols
Safety instructions in this document are framed and identified by a warning triangle
which is printed on a grey background.
Electrical hazards are identified by a lightning symbol surrounded by a warning
triangle.
Notes contain important information in cases where there is no risk of personal injury
or material losses and are identified by the symbol shown on the left. They are
bordered by horizontal lines above and below the text.
Symbol Meaning
B a step in an action sequence
Æ a reference to a related part in the document or to other related documents
• a list entry
– a list entry (second level)
Tab. 1
