Logamatic EMS RC35 programming unit - Subject to technical modifications
23
Operation with the user menu
5
5 Operation with the user menu
5.1 Introduction to the user menu
The user menu allows you to make specific settings. The procedure for operation is always the same:
1. Open the flap (by pulling the recessed grip on the left).
2. Press to open the USER MENU.
3. Turn rotary selector to change the selection.
4. Press to make your selection.
5. To change the value, hold down (the value starts flashing) and turn rotary selector at the
same time. Release .
The modified value is saved.
6. Press to go back one step.
Press several times or close the flap to return to the standard display.
Example: setting the continuous heating operating mode for heating circuit 1
Operation Result
1. Open the flap (by pulling the recessed grip on the left).
2. Press to open the USER MENU.
3. Turn rotary selector to the left until operation modes is
selected.
Tab. 8 How to use the user menu (example)
10:20h
21.5°C
02.12.2005
Fr
standard display
operation modes
switching programme
sum./win. threshold
USER MENU
standard display
operation modes
switching programme
sum./win. threshold
USER MENU
