Buderus RC35 User Manual

Operation with the user menu
Logamatic EMS RC35 programming unit - Subject to technical modifications
28
5
Designations of the heating circuits in the example in Fig. 2
When you make adjustments to a particular heating circuit, first select the appropriate heating
circuit. A list of designations as shown in Tab. 11 is available for selection.
Different temperatures for the heating circuits (Æ Tab. 11, [1] b) can also be entered using the
RC35 programming unit without a remote control, if your heating contractor has made
corresponding settings. In this case, the room temperatures for the separate heating circuit can be
set via the user menu (Æ page 37).
Fig. 2 For heating circuit 1+2:
Designation of the heating
circuits on the display
Setting the room
temperature
[1] Identical room temperature
(factory setting)
HC1+HC2 = RC35 heat. circuits
1)
1) No heating circuit selection is possible if no other heating circuit is available, e.g. DHW.
Page 14 – 16
[1] Different room temperatures
possible
2)
2) Here: adjustment by the heating contractor HC 1 = none, HC 2 = RC35.
HC1 = heating circuit 1
HC2 = RC35 heat. circuits
HC1: page 16 or 37
HC2: page 14 – 16
[2] Different room temperatures
possible
HC1 = heating circuit 1
HC2 = RC35 heat. circuits
HC1: via RC2x
HC2: page 14 – 16
Tab. 11 Designations of the heating circuits in the example in Fig. 2, page 27

Buderus RC35 Specifications

General

Display	LCD
Temperature Control	Yes
Weather Compensation	Yes
Communication	EMS Bus
Mounting	Wall-mounted
Voltage	24 V
Temperature range	5°C to 30°C
Accuracy	±0.5°C
Protection class	IP20
Weight	0.3 kg
Power consumption	2 W
Switching current	Not applicable
Ambient temperature	0°C to 45°C
