5
Installation of the boiler
Logano plus SB615 Gas - We reserve the right to make any changes due to technical modifications.
32
5.23.2 Fitting the burner to the burner plate
B Depending on the burner make or type, you must use
the corresponding burner plate or make necessary
alterations. Adjust the hole in the burner door thermal
insulation if necessary.
B Seal the gap between blast tube and lagging [1]
on-site.
Fig. 28 Sealing the gap between burner and insulation
(dimensions in mm).
1 Area between blast tube and thermal insulation
When fitting the burner (accessory), you
must observe the burner manufacturer’s
instructions.
