Buffalo U626 - Lubricating the Pusher Axle; Troubleshooting; Technical Specifications

5
UK
Lubricating the Pusher Axle
1. Push the carriage to one side and clean the axle with
dry a cloth.
2. Lubricate the axle surface with grease suitable for use
in food preparation areas.
3. Push the carriage backwards and forwards several
times to distribute the grease evenly.
Troubles hooti ng
Technical Specifications
Note: Ensure you use a grease that is suitable for use in a food preparation area.
Fault Probable Cause Action
The unit is not working The unit is not switched on Check the unit is plugged in correctly
and switched on
Plug and lead are damaged Call BUFFALO agent or qualified
technician
Fuse in the plug has blown Replace the plug fuse
Power supply Check power supply
Internal wiring fault Call BUFFALO agent or qualified
technician
Blade cover securing screw is
not properly inserted
Remove plate securing screw and
screw back in
The cradle hits the blade guard The carriage has been
improperly fitted
Unscrew the carriage knob, check the
carriage is properly in place then
replace the carriage knob
The blade is not cutting
properly/accurately
Blade is blunt Sharpen the blade
Plate securing screw is not
touching the plate
Tighten the securing screw
Model Voltage Power Current
Slicing
Thickness
Blade
Diameter
Max.
Slicing
Width
Dimensions
w x d x h mm
Weight
U626 230V 50Hz 180W 0.8A 0-12 mm 250mm 205mm 537 x 460 x
400
18Kg
U627 230V 50Hz 250W 1A 0-15 mm 300mm 205mm 597 x 520 x
495
25Kg
Carriage knob
Pusher axle
