49
PinApplication IMIX Type Values
J1-1 Program connector
J1-2 Program connector
J1-3 Program connector
J1-4 Program connector
J1-5 Program connector
J1-6 Program connector
J1-7 Program connector
J1-8 Program connector
J1-9 Program connector
J1-10 Program connector
J2-1 Auger 1Output 0 to 24 VDCAdjustable to change dispense rate
J2-2 Auger 2Output 0 to 24 VDCAdjustable to change dispense rate
J2-3 Auger 3Output 0 to 24 VDCAdjustable to change dispense rate
J2-4 Auger 4Output 0 to 24 VDCAdjustable to change dispense rate
J2-5 Auger 5Output 0 to 24 VDCAdjustable to change dispense rate
J2-6 Ground Gnd DC ground Self explanatory
J3-1 Display board I/O Comm Communication
J3-2 Display boardGRND GRND GRND
J3-3 Display board I/O Comm Communication
J3-4 Display boardOutput +8 VDC Display power supply
J4-1 N/AN/A N/AN/A
J4-2 Dispense/Whipper 1Output L1 activated with dispense
J4-3 Dispense/Whipper 2Output L1 activated with dispense
J4-4 Dispense/Whipper 3Output L1 activated with dispense
J4-5 Dispense/Whipper 4Output L1 activated with dispense
J4-6 Dispense/Whipper 5Output L1 activated with dispense
J4-7 N/AN/A N/AN/A
J4-8 Temp Sensor GRND GND
J4-9 Level Probe GRND GND
J4-10N/A N/AN/A N/A
J4-11Temp Sensor Input 0 to 5 VDCMonitors tank temperature
J4-12 Rinse position Input 0VDC in rinseSignals rinse position from rinse run switch
J4-13Inlet Output 120 VACInlet activated with refill circuit
J4-14Safety in Input L1 Float switch supplies refill only
J4-15L1Input 120 VACSelf explanatory
J4-16 Neutral/L2 Input N or 120VAC Nuetral or second leg
J4-17 Dispense/Whipper Output N or L2 Nuetral or second leg
J4-18 Dispense/Whipper Output N or L2 Nuetral or second leg
J4-19N/A N/AN/A N/A
J4-20N/A N/AN/A N/A
J4-21Ground grnd grnd Ground for rinse/run switch
J4-22N/A N/AN/A N/A
J4-23 Run Position Input 0VDC in runSignals run position from rinse run switch
J4-24 Level Probe signal Low AC Monitors tank level
J5-1 TransformerOutput 120 VACL1
J5-2 TransformerOutput 0 or 120VAC N or L2
J5-3 N/AN/A N/AN/A
J5-4 TransformerInput 24 VACSupplies power for board operation
J5-5 TransformerInput 24 VACSupplies power for board operation
iMIX-3S+/5S+ I/O 38831.####
INPUT/OUTPUT CHART
for IMIX-3S+ & 5S+
42032 060109
