Bunn IMIX User Manual

42
PinApplication IMIX Type Values
J1-1 N/AN/A N/AN/A
J1-2 Heater Output 120 VACTriac signal
J1-3 Safety in Input Float switch IMIX and ICED
J1-4 Neutral/L2 Input N or 120VAC Self explanatory
J1-5 L1 Input 120 VACSelf explanatory
J1-6 Light Output 120 VACTurns on Ballast
J1-7 Hot WaterOutput 120 VACSelf explanatory
J1-8 Inlet Output 120 VACInlet activated with refill circuit
J2-1 TransformerOutput 120 VACSelf explanatory
J2-2 TransformerOutput 0 or 120VAC Self explanatory
J2-3 N/AN/A N/AN/A
J2-4 TransformerInput 24 VACSupplies power for board operation
J2-5 TransformerInput 24 VACSupplies power for board operation
J3-1 Auger 1Output 0 to 24 VDCAdjustable to change dispense rate
J3-2 RPM sensor Input Signal Hall Effect
J3-3 RPM sensor Output 5 VDC +Power supply to Hall Effect
J3-4 RPM sensor Output NegativePower supply to Hall Effect
J3-5 N/AN/A N/AN/A
J3-6 Dispense/Whipper Output N or L2 Neutral or second leg
J3-7 Dispense/Whipper Output L1 Leg 1 activated with dispense
J3-8 Low powder detect? ??
J3-9 Low powder detectOutput 5 VDC +Sensor power supply
J3-10 Low powder detect? ??
J3-11Ground Gnd DC ground Self explanatory
J3-12N/A N/AN/A N/A
J3-13N/A N/AN/A N/A
J3-14N/A N/AN/A N/A
J4-1 Auger 2Output 0 to 24 VDCAdjustable to change dispense rate
J4-2 RPM sensor Input Signal Hall Effect
J4-3 RPM sensor Output 5 VDC +Power supply to Hall Effect
J4-4 RPM sensor Output NegativePower supply to Hall Effect
J4-5 N/AN/A N/AN/A
J4-6 Dispense/Whipper Output N or L2 Nuetral or second leg
J4-7 Dispense/Whipper Output L1 Leg 1 activated with dispense
J4-8 Low powder detect? ??
J4-9 Low powder detectOutput 5 VDC +Sensor power supply
J4-10 Low powder detect? ??
J4-11Ground Gnd DC ground Self explanatory
J4-12N/A N/AN/A N/A
J4-13N/A N/AN/A N/A
J4-14N/A N/AN/A N/A
J5-1 Auger 3Output 0 to 24 VDCAdjustable to change dispense rate
J5-2 RPM sensor Input Signal Hall Effect
J5-3 RPM sensor Output 5 VDC +Power supply to Hall Effect
J5-4 RPM sensor Output NegativePower supply to Hall Effect
J5-5 N/AN/A N/AN/A
J5-6 Dispense/Whipper Output N or L2 Nuetral or second leg
J5-7 Dispense/Whipper Output L1 Leg 1 activated with dispense
J5-8 Low powder detect? ??
J5-9 Low powder detectOutput 5 VDC +Sensor power supply
J5-10 Low powder detect? ??
J5-11Ground Gnd DC ground Self explanatory
J5-12N/A N/AN/A N/A
J5-13N/A N/AN/A N/A
J5-14N/A N/AN/A N/A
iMIX-3/4/5 I/O 37104.####
INPUT/OUTPUT CHART
for IMIX-3,4,5
42032 060109
