Bunn IMIX User Manual

43
J6-1 Auger 4Output 0 to 24 VDCAdjustable to change dispense rate
J6-2 RPM sensor Input Signal Hall Effect
J6-3 RPM sensor Output 5 VDC +Power supply to Hall Effect
J6-4 RPM sensor Output NegativePower supply to Hall Ef
fect
J6-5 N/AN/A N/AN/A
J6-6 Dispense/Whipper Output N or L2 Nuetral or second leg
J6-7 Dispense/Whipper Output L1 Leg 1 activated with dispense
J6-8 Low powder detect? ??
J6-9 Low powder detectOutput 5 VDC +Sensor power supply
J6-10 Low powder detect? ??
J6-11Ground Gnd DC ground Self explanatory
J6-12N/A N/AN/A N/A
J6-13N/A N/AN/A N/A
J6-14N/A N/AN/A N/A
J7-1 Auger 5Output 0 to 24 VDCAdjustable to change dispense rate
J7-2 RPM sensor Input Signal Hall Effect
J7-3 RPM sensor Output 5 VDC +Power supply to Hall Effect
J7-4 RPM sensor Output NegativePower supply to Hall Effect
J7-5 N/AN/A N/AN/A
J7-6 Dispense/Whipper Output N or L2 Nuetral or second leg
J7-7 Dispense/Whipper Output L1 Leg 1 activated with dispense
J7-8 Low powder detect? ??
J7-9 Low powder detectOutput 5 VDC +Sensor power supply
J7-10 Low powder detect? ??
J7-11Ground Gnd DC ground Self explanatory
J7-12N/A N/AN/A N/A
J7-13N/A N/AN/A N/A
J7-14N/A N/AN/A N/A
J8-1 Beeper Output 8 VDCSelf explanatory
J8-2 Beeper Output Ground Self explanatory
J9-1 External Novram External Novram External Novram
J9-2 External Novram External Novram External Novram
J9-3 External Novram External Novram External Novram
J9-4 External Novram External Novram External Novram
J9-5 External Novram External Novram External Novram
J10-1? Shorted to J10-13
J10-2?
J10-3?
J10-4?
J10-5?
J10-6?
J10-7?
J10-8?
J10-9?
J10-10 ?
J10-11 ?
J10-12 ?
J10-13 ?Shorted to J10-1
J11-1 Display boardOutput 8 VDC Display power supply
J11-2 Display board I/O Comm Communication
J11-3 Display boardGRND GRND GRND
J11-4 Display board I/O Comm Communication
INPUT/OUTPUT CHART (Continued)
for IMIX-3,4,5
42032 060109
