J12-1Temp Sensor Input Varistor

J12-2N/A N/AN/A N/A

J12-3 Level Probe signal Low AC Monitors tank level

J12-4 Level Probe grnd Low AC Monitors tank level

J12-5Temp Sensor Input ?

J12-6N/A N/AN/A N/A

J12-7 Run Position Input ?Signals run position from rinse run switch

J12-8N/A N/AN/A N/A

J12-9N/A N/AN/A N/A

J12-10 N/AN/A N/AN/A

J12-11 N/AN/A N/AN/A

J12-12 N/AN/A N/AN/A

J12-13 Ground grnd grnd Ground for rinse/run and day night switches

J12-14 Rinse position Input ?Signals rinse position from rinse run switch

J12-15 On position Input ?Signal on from day night switch

J12-16 Off position Input ?Signal off from day night switch

J13-1 Program connector

J13-2 Program connector

J13-3 Program connector

J13-4 Program connector

J13-5 Program connector

J13-6 Program connector

J13-7 Program connector

J13-8 Program connector

J13-9 Program connector

J13-10 Program connector

INPUT/OUTPUT CHART (Continued)

for IMIX-3,4,5

42032 060109
