LOWLANDER HD MK2 & WIDEBODY MANURE SPREADER – INSTRUCTION & SPARES MANUAL
Page 117
8. OPTIONS
8.1 SPRUNG DRAWBAR
KEY QTY PART No. DESCRIPTION
1 1 70440 GUDGEON PIN & NUT
2 2 70442/2 PIVOT PIN
1 70322/1 BOLT ON FIXED - STD
1 B5294 BOLT ON SCHARMULLER SWIVEL
1 70323 BOLT ON SCHARMULLER K80 SPOON
4* 1 N/A DRAWBAR TO SUIT MODEL
5 2 70438/1 SPRING 13 LEAF
6 3 70439/2 U-BOLT 30mm
3*
* NORTH AMERICAN STYLE CAT 3, 4 & 5 (Contact your local dealer or GT Bunning)
DRAWBAR ASSEMBLIES: The North American style mounting available upon request.
HITCHES: The North American style Swivel and Clevis hitches available upon request.
