15. TECHNICAL DATA & SPECIFICATIONS
15.1 MECHANICAL DATA & SPECIFICATIONS
150HD 175HD 180 230
GROSS DESIGN Kg 21750 25750 25000 31000
AXLE DESIGN Kg 18000 22000 20000 13000x2
AXLE GB Kg 10170 10170 10170 9000x2
EYE Kg 3570 3750 5000 5000
TARE WEIGHT Kg 6540 7350 7000 8000
PAYLOAD Kg 15000 17500 18000 23000
PAYLOAD + TARE Kg 21540 24850 23000 31000
AXLE SIZE 150 SQ 150SQ 150 SQ 130 SQ
MODEL
Bunning tolerance +/- 2%
150HD 175HD 180 230
Axle SINGLE SINGLE SINGLE TANDEM
Axle beam size 150mm 150mm 150mm 110mm
Carrying capcacity 15000 Kg 17500 Kg 18000 Kg 23000 Kg
Cubic meters 13 level/17 heaped 18 level/22 heaped 10 level/14 heaped 10 level/14 heaped
Extended sides N/A N/A
17 up to 26 heaped
17 up to 26 heaped
Body size (int.mm)
5950x1600x1295mm 5950x1600x1580mm
6050x1830x950 6050x1830x950
Floor drive Hydraulic Hydraulic Hydraulic Hydraulic
Floor speed control
Floor chain size 20mm 20mm 20mm 20mm
Brake size mm 406x140 420x200 406x140 400x80
Tyre size 580/70 R38HL 710/70 R42 710/70 R38 650/55 R26.5
Spread Mech Twin vertical augers Twin vertical augers Twin vertical augers Twin vertical augers
Spread width Up to 20 meters Up to 20 meters Up to 20 meters Up to 20 meters
PTO speed 1000 RPM 1000 RPM 1000 RPM 1000 RPM
Floor plate 5mm 5mm 5mm 5mm
Side plate 4mm 4mm 4mm 4mm
MODEL
Hydraulic variable speed c/w reverse
NB – Machines with extension sides or built-in flares are designed for use with light
materials. DO NOT EXCEED THE PLATED WEIGHTS.
USE ON HIGHWAYS (UK)
Maximum gross combination weight is 31000 Kg.
Maximum spreader weight is 18290 Kg.
