LOWLANDER HD MK2 & WIDEBODY MANURE SPREADER – INSTRUCTION & SPARES MANUAL
Page 61
4.13 TRANSVERSE DRIVE ASSEMBLY HORIZONTAL BEATERS CAM CLUTCH
KEY QTY PART No. DESCRIPTION
1 1 42506 TORQUE LIMITER ASSEMBLY 1-3/4" TO 6 SPLINE
2 1 DMS1328-17 DRIVE SHAFT WIDEBODY SRT18
2 1 DMS1328-15 DRIVE SHAFT WIDEBODY SRT20
3 1 DMS0263-03 KEY 12x8
4 1 73898 GRUB SCREW M12 x 16LG
5 1 DMS0326 KEY 14x9
Factory set Torque limit at 2900 Nm (138 bar)
