LOWLANDER HD MK2 & WIDEBODY MANURE SPREADER – INSTRUCTION & SPARES MANUAL
Page 66
5.5 WALTERSCHIED WIDE ANGLE PTO SHAFT – SHEAR BOLT
PART No. TRACTOR END SPREADER END LENGTH REF
43004 1 3/8" 6 SPLINE 1 3/4" 6 SPLINE 1210mm
43004/1 1 3/4" 20 SPLINE 1 3/4" 6 SPLINE 1210mm
43004/2 1 3/8" 21 SPLINE 1 3/4" 6 SPLINE 1210mm
43005L 1 3/8" 21 SPLINE 1 3/8" 6 SPLINE 1510mm AUSTRALIA ONLY
43006L 1 3/8" 6 SPLINE 1 3/8" 6 SPLINE 1510mm AUSTRALIA ONLY
43007L 1 3/4" 20 SPLINE 1 3/8" 6 SPLINE 1510mm AUSTRALIA ONLY
NOTE: All PTO shafts meant for Australia and used on the T80 driveline will have the spreader end
updated to 1 ¾” 6 spline.
5.6 WALTERSCHIED WIDE ANGLE PTO SHAFT – TORQUE LIMITER
PART No. TRACTOR END SPREADER END LENGTH REF
43004/2TL 1 3/8" 21 SPLINE 1 3/4" 6 SPLINE 1210mm 2 CAM
43008 1 3/4" 20 SPLINE 1 3/4" 6 SPLINE 1510mm 4 CAM
