5. DESCRIPTION
5.1. Area of application
• The chlorine sensor type 8232 is used to measure the chlorine
concentration in liquids.
• The "trace" chlorine sensor type 8232 is used to measure the
chlorine concentration in liquids at very low concentrations or to
monitor the absence of chlorine. This sensor can be used in water
without containing any chlorine up to four weeks.
The sensor must be installed in an analytical measurement chamber
type 8200. See chap. 10.2.
5.2. Knowing the sensor
Chlorine sensor "Trace" chlorine sensor
seal
shaft
M12
male fixed
connector
shaft
counter
electrode
internal holder
("G-holder")
4-pin connector
with cable
(ordered
separately)
snap ring
slide ring
seals
reference
electrode
working
electrode
hose ring
(covers the
vent)
hose ring
(covers the
vent)
membrane cap
membrane membrane
membrane
holder
Fig. 1 : Description of the sensor
