Burkert TopControl ON/OFF User Manual

34
Top Control ON/OFF
english
Terminal Connection External circuit
No.
1 Supply for limit switch + 24 V
2 Supply for limit switch GND
3 Output, limit switch 1 (NO)
4 Output, limit switch 1 (NC)
5 Reference for limit switch 1
GND
6 Output, limit switch 2 (NO)
7 Output, limit switch 2 (NC)
8 Reference for limit switch 2
GND
9 Valve drive 0 V / 24 V
10 Valve drive GND
+24 V DC
NC1 24V/0V (max. 5 A)
NO1 0V/24V (max. 5 A)
NC2 24V/0V (max. 5 A)
NO2 0V/24V (max. 5 A)
GND
GND
Terminal Connection External circuit
No.
1 Supply for proximity switch
+ 24 V
2 Supply for proximity switch
GND
3 Vinary output, proximity
switch 1 (NO)
4 not used
5 Reference for proximity
switch 1 GND
6 Binary output, proximity
switch 2 (NO)
7 not used
8 Reference for proximity
switch 2 GND
9 Valve drive 0 V / 24 V
10 Valve drive GND
+24 V DC
(Residual ripple10%)
1
3
6
5
2
S2
S1
Output 1 (0V/24V)
Output 2 (0V/24V)
GND
GND
24 V variant with inductive proximity switches (normally open)
8
GND
24 V variant with mechanical limit switches
1
4
7
6
5
S2
S1
9
10
0/24 V DC ± 10 %
2
3
8
GND
9
10
0/24 V DC ± 10 %
