3 INSTALLATION
3.2 Installation of the TopControl ON/OFF Type 8633 onto
the valve drive
The dimensions of the Top
Control
ON/OFF and the various complete unit
variants consisting of TopControl ON/OFF, pneumatic drive and valve can be
found in the corresponding data sheets.
The dimensions and thread types can be found in the data sheet of the
process valve.
3.1 Installation of the valve
3.2.1 General Notes
The installation of the Top
Control
ON/OFF Type 8633 onto the valve drive and
setting up the switching points of the limit switches is carried out in a single
sequence for this unit, and is the same for the mechanical and the inductive
variants.
An accessory set is necessary for connecting the Top
Control
to the valve
drive. This contains all the components that are necessary for the mechanical
and pneumatic connections. The accessory sets are available with hoses of
the necessary lengths, corresponding to the size of the valve drive.
The order numbers of the sets are listed in the technical data sheet.
